Size Guide
Find the perfect gaylord box size for your needs. Our comprehensive guide covers all standard dimensions and specifications.
Get a Free Quote
Standard Gaylord Sizes
| Name | Dimensions (L x W x H) | Volume (cu ft) | Typical Capacity | Best For |
|---|---|---|---|---|
| Standard Full | 48" x 40" x 36" | 40 | 2,000+ lbs | General bulk storage |
| Standard Tall | 48" x 40" x 48" | 53 | 2,500+ lbs | Lightweight bulky items |
| Standard Short | 48" x 40" x 24" | 27 | 1,500+ lbs | Heavy dense materials |
| Half Gaylord | 48" x 40" x 18" | 20 | 1,000+ lbs | Small parts, samples |
| Octagon | 48" x 40" x 41" | 42 | 2,000+ lbs | Produce, round items |
| Extra Tall | 48" x 40" x 60" | 67 | 2,000+ lbs | Very light items |
| Wide | 48" x 48" x 36" | 48 | 2,200+ lbs | Square pallets |
| Produce | 40" x 48" x 28" | 31 | 1,500+ lbs | Agricultural products |
Understanding Dimensions
Gaylord box dimensions are typically listed as Length x Width x Height. The standard 48" x 40" footprint matches a GMA (Grocery Manufacturers Association) pallet, which is the most common pallet size in North America.
How to Choose
Consider Your Product
- Weight of contents
- Shape and size of items
- Stacking requirements
- Access needed during storage
Think About Space
- Warehouse ceiling height
- Forklift clearance
- Truck/trailer dimensions
- Storage rack compatibility
Plan for Handling
- Loading/unloading method
- Pallet jack access
- Manual handling needs
- Shipping requirements
Wall Types
Double Wall
Two layers of corrugated material. Good for general-purpose applications with moderate weight requirements.
- • Standard strength
- • Cost-effective
- • Good for items up to 1,500 lbs
Triple Wall
Three layers of corrugated material. Maximum strength for heavy-duty applications and export shipping.
- • Maximum strength
- • Excellent stacking
- • Ideal for 2,000+ lbs
Size by Application
Automotive Parts
- 48x40x36" - metal parts
- 48x40x48" - plastic components
- 48x40x24" - heavy castings
Food & Beverage
- 48x40x28" - produce
- 48x40x36" - dry goods
- Octagon - fruits & vegetables
Pharmaceuticals
- 48x40x36" - packaged goods
- 48x40x24" - heavy bottles
- 48x40x18" - small vials
Recycling Centers
- 48x40x48" - plastics
- 48x40x60" - lightweight materials
- 48x48x36" - mixed materials
Textiles & Apparel
- 48x40x48" - clothing
- 48x40x60" - linens
- 48x40x36" - fabric rolls
Electronics
- 48x40x36" - components
- 48x40x24" - heavy equipment
- 48x40x48" - packaging materials
Volume Reference
| Height | Volume (48x40 base) | Approx. Bushels | Approx. Gallons |
|---|---|---|---|
| 18" | 20 cu ft | 16 | 150 |
| 24" | 27 cu ft | 21 | 200 |
| 28" | 31 cu ft | 25 | 230 |
| 36" | 40 cu ft | 32 | 300 |
| 41" | 46 cu ft | 36 | 340 |
| 48" | 53 cu ft | 42 | 400 |
| 60" | 67 cu ft | 53 | 500 |
* Volume calculations based on standard 48" x 40" base dimensions. Actual usable volume may vary.
Stacking Guidelines
Safe Stacking Practices
- Never stack more than 3-4 boxes high
- Place heaviest loads at the bottom
- Ensure contents are evenly distributed
- Check for structural damage before stacking
- Use edge protectors for added stability
- Allow for air circulation between stacks
Maximum Stack Heights
Grade A (Premium)
Max: 4 boxes - Up to 2,500 lbs each
Grade B (Standard)
Max: 3 boxes - Up to 2,000 lbs each
Grade C (Economy)
Max: 2 boxes - Up to 1,500 lbs each
Pallet Compatibility
GMA Pallet (48" x 40")
The most common pallet in North America. Standard gaylord boxes are designed to fit perfectly on this pallet size.
Compatible Sizes:
- • Standard Full
- • Standard Tall
- • Standard Short
- • Half Gaylord
- • Octagon
Square Pallet (48" x 48")
Common in chemical and drum industries. Requires wider gaylord boxes for proper fit.
Compatible Sizes:
- • Wide (48x48x36")
- • Custom square sizes
Half Pallet (48" x 20")
Used for smaller loads and retail displays. Requires custom-sized gaylord boxes.
Compatible Sizes:
- • Custom half-size boxes
- • Modified standard boxes
Measurement Tips
How to Measure
- 1Length: Measure the longest side (front to back)
- 2Width: Measure the shorter side (side to side)
- 3Height: Measure from base to top edge
- 4Always measure inside dimensions for capacity
- 5Measure outside dimensions for storage planning
Important Notes
- Used boxes may vary slightly from stated dimensions
- Allow 1-2" tolerance when planning storage
- Check clearance heights for forklifts and doors
- Consider product overhang when selecting height
- Flaps add approximately 4" when closed
